OPTEX - WIRELESS DRIVEWAY ALARM 400M RANGE WITH SIREN - RCTD-400S

THIS ITEM IS NOW DISCONTINUED, WE STRONGLY RECOMMEND ITEM BELOW

http://map-security.com/dakota-wireless-external-driveway-long-range-alarm-kit.html

---------------------------------------------------------------------------------------------

Product Description
Product Description

Optex is the Japanese world leader in sensor technology and they supply products products to all higher end establishments across the world such as Banks / MOD / Industrial sites ect......The cost is higher than your typical sensor system BUT the performance/ reliability is unmatched by any other manufacturer globally!

This stylish Driveway Alarm system has an impressive working range of 400 metres and is suppied with an 100Db external siren.
A perfect solution for short/medium range applications where our customers want the intruder to know they have been detected, the siren will only activate from 5 to 60 seconds (adjustable), long enough to be heard, short enough not to be a nuisance to neigbours.
Simply mount the fully waterproof PIR in the best location for detection, either high up looking down, or 1 metre from the ground looking parallel across the ground, powered by a simple 9v PP3 battery that will last up to one year.Mount the receiver inside the house on a wall or desk, mount the weatherproof siren inside or outside and connect it to the receiver via the 3 metres of cable supplied, plug two transformers into a standard 13-amp wall sockets.The perfect solution for small/medium size houses & businesses to be alerted inside to the presence of a visitor whilst at the same time the visitor being aware that they have been detected. The system can be used with just the chime system working for times that a siren is not required, our customers often choose to put the siren on at night or when they are away from home.
The detection range of the PIR can be up to 14 metres depending on the settings.

Additional transmitters and receivers are available to suit all applications, some customers have three or four detectors and one receiver, some have one detector and two receivers, we can suit all applications.

The unique mounting system allows sensor to be located behind post or tree for hidden applications and the exclusive sensor eye allows invisible beam to be adjusted to a very narrow pattern for driveway and perimeter applications.

We offer a wide range of compatible sensors to work with the RCTD-400 such as additional PIR's, external / internal sirens / additional reciever , repeater (to extend range), Xenon beacon. This particular kit includes a live sounder/ tannoy that is driven/powered from Optex reciever.

Typical applications that we have supplied this product into are:

• Driveway/Entry Alert
• Perimeter awareness
• CCTV Trigger
• Warehouse Delivery
• Construction Site
• Shoplifting Control
• Pool Guard
• Drive-up Windows
• Display Cases
• Emergency Exits
• Home Automation (automatic driveway / porch lights )
• Patient monitor
• Temporary Spot Protection

  Receiver:
  Size: 130mm (H) x 90mm (W) x 30mm (D)
  Wall or Desk Top Mount
  Power: 9v DC Transformer (supplied)
  Relay Output: Form 'C', max 1A x 50vAC, 24v DC
  Output Timer: Selectable 1/5/30/60 seconds
  Status Indicator: Power Indicator: Green, Zone 3 x Red
  Operating Temperature: -10 C - +40 C

  PIR:
  110mm (D) x 110mm (L) x 89mm (W)
  Power Supply = 9v PP3 Battery
  Designed to be mounted above a door looking down, or side mounted looking across.
  Beam Pattern: Adjustable, wide or narrow.
  Beam Length: 14m (L) max, 4m (W) max.
  Typical Battery Life: 6 - 12 months.
  Detection Method: Passive Infrared.
