Product Description
The Scantronic EXP-W10 is a 10 zone wired expander designed for the i-on160EX.
This expander provides connections for:
- Either 10 Fully Supervised Loop zones OR five Closed Circuit Loop zones.
- One loudspeaker.
- Four, wired, programmable outputs.
The unit is housed within a white plastic case, which has a built-in shrouded back tamper and internal clips to hold the I-roc1 four relay output expander card.
In addition the expander pcb contains:
- Memory request button used during device addressing
- Two digit LED display to show bus address and software version. A piezo sounder for use in the Tracer bus device locator.
Product Features
• One button push for semi-auto addressing ensuring a unique device address and speeding up installation
• Green heartbeat LED diagnostics tool
• 16ohm speaker connection
• EXP-W10 includes a mounting for clean contact relay board (i-RC01)
Specification
| PD66620:2010 Grade: | Grade 3 |
| Environmental Class: | Class 2 |
| Dimensions H x W x D (mm): | EXP-PSU: 427 x 400 x 101 EXP-W10: 230 x 144 x 44 |
